无卤低烟阻燃聚烯烃绝缘环保电线
Non-sheathed cables for fixed wiring
一、执行标准 Executive Standard
产品按照Q/YL13-2012设计制造
It is manufactured according to Q/YL13-2012 standard
二、用途 Application
本产品主要用于额定电压450/750V及以下动力装置线路固定布线
It is used for fixedly laying in engine devices of AC. Rated voltge 450/750V or ower.
三、产品型号及名称 Type Designation
|
型号Type |
名称Designation |
额定电压Rating(V) |
芯数
Core number
|
标称截面(mm2)Norminal area of conductor |
|
WDZA-BYJ |
一般用途单芯硬导体无护套无卤低烟阻燃A类环保电缆 |
300/500 |
1 |
0.5-1 |
|
450/750 |
1 |
1.5-400 |
|
WDZB-BYJ |
一般用途单芯硬导体无护套无卤低烟阻燃B类环保电缆 |
300/500 |
1 |
0.5-1 |
|
450/750 |
1 |
1.5-400 |
|
WDZC-BYJ |
一般用途单芯硬导体无护套无卤低烟阻燃C类环保电缆 |
300/500 |
1 |
0.5-1 |
|
450/750 |
1 |
1.5-400 |
|
WDZAN-BYJ |
一般用途单芯硬导体无护套无卤低烟阻燃A类耐火环保电缆 |
450/750 |
1 |
1.5-400 |
|
WDZBN-BYJ |
一般用途单芯硬导体无护套无卤低烟阻燃B类耐火环保电缆 |
450/750 |
1 |
1.5-400 |
|
WDZCN-BYJ |
一般用途单芯硬导体无护套无卤低烟阻燃C类耐火环保电缆 |
450/750 |
1 |
1.5-400 |
四、使用特性 Using Features
产品具有一系列优异的性能，不含有卤素，不产生有害气体及腐蚀性气体；燃烧发烟量少，不含有铅等重金属，不污染土壤；
1.电线导体的最高额定温度为90℃
2.电线敷设时的环境温度最低不低于0℃；
3.最小弯曲半径：电线外径小于15mm为6D，15mm-25mm为8D，大于25mm为10D（D为电线的外径）。
The prouduct has aseries ofperfor-mances,not Release harmful gas and corrosion gases;Low-smoking ,without pollution-creating pollute soils.
1.Max.Temperatue of conductor:90℃
2.The installation temperature should not Less than 0℃
3.The bending radius of cable should not less than 15Mm(6D),15mm-25mm(8D),and over 25mm(10D)(Dmeas outer diamerer of cable)
五、交货长度 Delivery length
产品交货长度按双方协议规定，计量误差不超过±0.5%。
Delivery length is decided by the seller and buyer length error allowance of no more than ±0.5%。
